PX30i is capable of high volume and high mix production 5 axis machine inheriting the DNA of YBM series.

Important Specifications

Travel (X,Y,Z)

680x400x500mm

Pallet working size

Dia.185mm

Loading capacity

80 Kg

Spindle rpm (BBT40)

20,000min⁻¹

PX30i
Free of charge
Consultation
appointment
request
ProductdetailsMedia libraryDownload CenterRelated Machines
HomeVertical 5-Axis

Productdetails

PX30i
5-Axis
Vertical

Machine Structure

The highly rigid integrated portal structure dominates the field of high precision and heavy cutting.

PX30 Machine
PX30 Machine

Spindle

The preload self-adjusting spindle developed by YASDA realizes a high degree of accuracy through whole speed range.

PX30 Spindle
PX30 Spindle

NC

15" touch panel display mounted with FANUC iHMI interface and YASDA's User interface "OpeNe Version 2.0" provide intuitive operation and high functionality. The "OpeNe version 2.0" provide the operator with complete details of the machine and innovative solutions.

NC
NC

ATC/APC

ATC: PX30i is equipped with an automatic tool changer (ATC) with 323 tools standard. With an additional magazine the number of tools can be expanded up to 512 tools.


PLS: 33 Pre Load Stand (33 PLS) is also as standard.

PX30 ATCAPC
PX30 ATCAPC

Specifications

Travel (X,Y,Z) : 680x400x500mm

   (B) : -125~+65deg

   (C) : 360deg(Continuous)

Pallet working size: Dia.185mm

Max. Workpiece : Dia.400x315mm (limitation)

Loading capacity : 80kg

Spindle : 20,000min-1

Spindle Taper : BBT40 [ HSK-A63 (op) ]

Rapid traverse (X,Y,Z): Max. 60,000mm/min

Table tilting speed (B) : Max. 75min-1

Table Rotation speed (C) : Max. 125min-1

ATC capacity : Max. 323 tools [ Max. 512 tools (op) ]
